View larger

Manufacturer: YAESU

Reference: YAESU-G-450CDC-1433

Condition: New product

Country of origin:

Japan

Yaesu G-450 CDC 100kg antenna rotor new model

Read the 9 reviews

Average rating: 5/5 Number of reviews: 9

Yaesu G-450CDC antenna rotator for maximum vertical load of 100kg.

Requires optional mast support GC-038 to be mounted on top of the mast.

Wind load: 1m²
Stationary torque: 3000kg/cm
Rotating torque: 600kg/cm
Maximum vertical load: 100kg
Mast diameter: 32-63mm
360° rotation time: 63s
Dimensions: 186mm x 263mm
Rotor weight: 3.5kg
Console weight: 2.3kg
Cable type: 4 wires
Power supply: 220V
Rotor power supply: 20V
1-year warranty

Delivered with : 1 rotor G-450 -CDC, 1 control panel, 1 rotor 7 pins connector, 1 6 pins connector for the control panel. Available in option below the control cable in 25m or 40m length.

More details

Download

Yaesu Rotators connexion

118.46k

Specifications Yaesu rotators

1.27M

Yaesu G-450 Manual (FR)

Yaesu G-450 CDC Rotor Manual in French 748.71k

Data sheet

Please note: As of 2019, the new G-450CDC rotor operates with a 20V DC supply voltage and a 4-wire connector system.

The older Yaesu G-450C rotors and control consoles that used a 5-wire 26 VAC voltage are NOT compatible with the new CDC version, and the control consoles in the new CDC version are NOT compatible with the older G-450C series rotors.
