New Baofeng UV-6R VHF-UHF 5W Baofeng HT Handheld BAOFENG-UV6R-471 View larger

Baofeng

BAOFENG-UV6R-471

New product

China

New Baofeng UV-6R VHF-UHF 5W

The new walkie-talkie Baofeng UV-6R is the new improved version of the famous UV-5R. It covers transmission and reception from 136 to 174MHz (VHF) and 400 to 520MHz (UHF) with 5 watts real in VHF and UHF on the amateur radio bands 144 / 430Mhz.

More than just a change of case, the UV-6R is equipped with the new firmware HDBF230, it is also more sensitive than the UV-5R, with a more powerful loudspeaker, a larger antenna (15cm). The menu and functions remain identical to the UV-5R.

This material is no longer available in the shop and replaced by the new TYT TH-UV88 walkie-talkie which offers a better reception.

Comes complete with: Baofeng UV-6R, desk charger 220V EU plug, earphone-microphone, belt clip, VHF-UHF antenna, BL-6 1800mAh battery and manual in English. Warranty 2 years by Passion Radio.

Improve performance with a larger antenna such as: Diamond Antenna SRJ77CA and Nagoya NA-771.

More details

Download

Baofeng UV6R Software

Official Baofeng programming software for UV-6R 1.73M

UV-6R prog file for Chirp

UV-6R ready-to-use programming file (+ 70 frequency in France) for CHIRP software (.IMG) 8.02k

UV-6R prog file for BAOFENG

UV-6R ready-to-use programming file (+70 frequency in France) for Baofeng software (.DAT) 13.39k

Manual UV-6R FR

Official manual for Baofeng UV-6R (in French). 606.76k

Manual UV-6R (EN)

In english 640.82k

Data sheet

Baofeng / Pofung UV-6R Specifications

    Dual-Band Display, Dual Standby Frequency
    Output Power: 1/5 Watts
    128 channels, 50 CTCSS and 104 CDCSS
    VOX, Tone 1750Hz
    Antenna Connector: SMA Male
    FM Radio (87MHz-108MHz)
    Led lamp
    LCD screen
    Frequency Scan
    Step increment: 2.5 / 5 / 6.25 / 10 / 12.5 / 25KHz
    Roger beep

2 Year Warranty by Passion Radio
CE and RoHS standards

UV6R Improvements & UV5R comparison

The Baofeng UV-6R offers a better grip, thanks to its size slightly larger than a UV-5R and a little smaller than the UV-82.

The new HDBF230 firmware corrects bugs and offers a higher level of sensitivity for improved reception on weaker signals. The increase of the length of the antenna (15cm) also helps improve reception of radio signals.

The number of keys has been reduced to 16, to limit handling errors. The function keys have been integrated and reorganized. The keys of the UV6R and especially the PTT button are made of soft rubber instead of ABS plastic (UV5R).

The UV-6R is equipped with a 16 ohm loudspeaker (instead of 8 ohm on the UV5R), for a more powerful and clear listening, especially in noisy environment.

The UV-5R charger can be used for the UV-6R, it is necessary to make sure the device is placed at the bottom of the charger so that the contact does it correctly. And the UV-5R charger can also be used for UV6R. However battery of UV5R does not fit to UV6R.

The Baofeng programming USB cable is compatible as well as accessories with kenwood K2 plug. The Baofeng programming software is specific to the UV-6R and can be downloaded below. The free Chirp programming software can also be used.

Reminder: The Baofeng UV-6R is walkie-talkie with license radio and subject by the user to respects of authorized frequencies and power.
