PCB transceiver 2.4 Ghz + Bluetooth 5.0 nRF52832 EBYTE

No review at the moment

Transceiver 2.4 Ghz and Bluetooth 4.2/5.0 PCB module, based on the RF chip nRF52832, with a power of 2.5mW and IPEX / U.FL antenna connector.

The ultra-low-power nRF52832 chip supports BLE 5.0 and 2.4 GHz wireless applications, with 512 KB of flash memory and 64 KB of RAM. The nRF51 and nRF24L series are compatible.

Fields of application: IoT, smart home sensors, voice-activated control, intelligent surveillance, building automation and installations.

Delivered with: 1 EBYTE PCB module transceiver E73-2G4M04S1B.

More details

Download

Manual EBYTE E73

835.16k

Wiring diagram E73-2G4M04S1B

233.65k

Data sheet

Specifications nRF52832 EBYTE E73

32-bit ARM Cortex-M4F processor
Operating voltage 1.7V to 3.6V
512 KB of flash memory + 64 KB of RAM
Supports simultaneous operation of the BLE / ANT protocol
Output power +4 dBm (2.5mW)
Bluetooth BLE: 4.2 and 5.0
Sensitivity -96dBm, BLE
Bitrates: 2 Mbps or 1 Mbps
Automatic power management system
Configurable I / O
3 SPI xMaster / Slave
2 xTWI (I2C)
UART (RTS / CTS)
AES HW Encryption
12bit ADC
Real time clock (RTC)
Digital microphone interface (PDM)
Rohs, CE and FCC certified
