Baofeng DM-5R : Bi-bande FM & DMR Tier 2 (V3)

The new 2018 (V3) version of the Baofeng DM-5R is a VHF-UHF, FM and DMR walkie-talkie, in Tier2, TDMA (2 Timeslot), compatible in DMR mode via repeater or hotspot.

The DM-5R use same case and main features of the walkie-talkie UV-5R, VHF-UHF dual band, compact, RX and TX VHF 136-174MHz and UHF 400-480 MHz, 4 watts FM maximum, equipped with an 88-108Mhz FM radio and a led lamp.

Comes complete with: Baofeng DM-5R (V3 TDMA 2 TimeSlot - Tier 2), desktop charger, antenna, battery, programming cable included, belt clip, lanyard, manual in English.

Note: The programming cable for the Baofeng UV-5R analog FM walkie-talkie is not compatible with the DM-5R or RD-5R. All other UV-5R accessories are compatible with the DM-5R and RD-5R.

This DMR walkie-talkie is also proposed by Radioddity with reference RD-5R, only the case changes, RD-5R is manufactured by Baofeng for Radioddity.

More details

Download

Manuel DM-5R (EN)

2.43M

Firmware Update Software DM-5R

Baofeng DM-5R & Radioddity RD-5R firmware update software with firmware V2.1.6 Aout 2018 6.48M

DM-5R CPS software

CPS software V1.0.0.4 for programming Baofeng DM-5R / Radioddity RD-5R. 703.47k

Firmware V2.1.6 DM-5R

Firmware V2.1.6 - August 2018 for DM-5R & RD-5R 481.24k

Guide DM5R F4IEW (FR)

In french. 832.01k

Data sheet

Baofeng DMR DM-5R dualband (V3)

1 x Battery 7.4V 2000mAh Li-ion
1 x Antenna 136-174 / 400-480 MHZ
1 x Belt Clip
1 x English manual
1 x Desktop Charger (100V ~ 240V) EURO
1 x PTT headset
1 x DM-5R programming cable

DMR HandHeld DM5R specifications

Dual-Band Display, Dual Frequency Standby
Output power: 1/4 Watts
128 channels, 50 CTCSS and 104 CDCSS
FM and DMR mode
TDMA, Tier 2, 2 TimeSlot
VOX, Tone 1750Hz
FM Radio (65.0MHz-108.0MHz)
Led lamp
Large LCD screen
Switchable 25KHz / 12.5KHz in FM
Emergency alert function
Frequency monitoring
No incrementation: 2.5 / 5 / 6.25 / 10 / 12.5 / 25KHz
Roger beep

2 year warranty and CE and RoHS standards.

Reminder: The use of any radio transmitting device and the Baofeng DM-5R handheld DMR is subject to the respect of the user of the frequencies and the legislation in force and requires a radio license to be used legally.
